Gi wire Mesh Cable Tray
Our Bendin gi wire mesh cable tray adopts galvanized iron material for rust resistance, with open mesh design delivering outstanding heat dissipation to protect cables.
Specifications of Gi wire Mesh Cable Tray
The specific specifications of the Bendin gi wire mesh cable tray depend on the project.
| Material |
Electro-galvanizing, hot-dip galvanizing,hot-dip galvanizing |
| Width |
50mm(2"),100mm(4"),150mm (6"),200mm(8"),250mm(10"),300mm (12"), 450mm (18"), 600mm (24")
|
| Depth |
50mm(2"),75mm(3"),100mm(4"),150mm (6"),200mm(8"),250mm(10")
|
| Length |
3 m(10 ft) |
| Support Span |
1.8m(6 ft),2.4m(8 ft),3.0m(10 ft),3.6m(12 ft),4.8m(16 ft),6.0m(20 ft),7.2m(24 ft),9.0m(30 ft)
|
| Wire Diameter |
3.5mm,4mm,4.5mm,5mm,5.5mm,6 mm |
| Accessories |
90° & 45° Bends (Horizontal), Risers (Vertical Bends), Reducers, Crosses, Tees, Dividers |
Typical Projects for Gi wire Mesh Cable Tray
The Bendin gi wire mesh cable trays are specified in projects where corrosion resistance, hygiene, open ventilation, aesthetic appeal, and long-term durability are critical.
| Project Category |
Specific Applications & Rationale |
| Corrosive & Hygienic Industrial Environments |
Chemical & Pharmaceutical Plants
Food & Beverage Processing
Marine & Coastal Facilities
Water/Wastewater Treatment Plants
|
| High-Tech & Critical Infrastructure |
Data Centers & Server Rooms
Telecom & 5G Infrastructure
Cleanrooms (Semiconductor, Biotech, Life Sciences)
|
| Public & Commercial Facilities |
Transportation Hubs (Airports, Subways)
Hospitals & Laboratories
Museums, Arenas, Auditoriums
|
| Outdoor & Utility Applications |
Solar Power Plants (PV Farms)
Tunnels & Underground Passages
|
| Hazardous & Safety-Critical Areas |
Oil & Gas (Onshore/Offshore)
Mining & Heavy Industry
|
Frequently Asked Questions
1. Are you a manufacturer?
Yes, we have been in this field for over 30 years.
2. Can you provide samples?
Yes, we can provide samples with our product catalog. (However, the express delivery cost will be borne by you.)
3. What payment terms do you accept?
Payment methods: Wire transfer (T/T), Letter of Credit (L/C), MoneyGram, Credit Card, PayPal, Western Union.
4. What are your shipping terms?
FOB, CNF, CIF, DDU, DDP.
5. What is your delivery time?
We always have ample stock of materials to meet your urgent needs. The fastest delivery time is only 10 days. After placing an order, we will send you the exact delivery time and production schedule.
